DESCRIPTION

Basic Info

Model NO.	movable wall panels
Surface	MDF Board, Fabric, Leather
Type	Melamine MDF Panel, Fireproof PVC Board, Fabric(Le
Application	Office, Hotel Banquet Hall, etc.
Main Material	Aluminum Frame and Track
Soundproof Mater	Rock Rool , Glass Wool
Soundproof Stc	40dB-50dB
Dimensions	W700-1200mm, H2000-5200mm, Thickness 80-110mm
Stacking Way	Centre Partiting; Side Parking
Open Way	Sliding Partition
Transport Package	Carton Paper Packaging, MDF Batten Cover Corners
Specification	Customized
Trademark	MQ Acoustics
Origin	China
HS Code	76101000

Product Description

Movable partition is a movable wall with general wall functions that can divide large space into small space or connect small space into large space at any time according to needs. It can play a role of multiple functions in one hall or one room. The acoustic movable walls brings great convenience to people's work. For example, you can fold it on one side when you need it, so that the two spaces are temporarily joined to make them appear larger, which is convenient for temporary departmental meetings.

Specifications

Type	65 type, 80 type, 100 type, ultra high 100 type.
Finish	melamine MDF panel, fireproof PVC board, fabric(leather) wrapped MDF panel, fabric(leather) wrapped fiberglass panel
Density	28~32kg/m²
STC	40db-50db
Dimensions	width 700~1200mm, height 2000~5200mm, thickness 80~110mm, rail load 450kg
Structure	25mm PAR fiberglass panel(24kg/m2 ) , 9mm base panel, 6063-T6 aluminum sectional material, durable NBR modified rubber for sealing

Product Details
Product Structure



Panel Suspension	Top hunge system without the need for a floor track.
Panel Width	Each panel 600mm-1200mm.
Track	Aluminum OR Steel Track
Roller on panel	Single or double roller.
Panel Frames	Heavy-duty steel-gusseted aluminum inner frames reinforced with full height.
Top&bottm seals	Top and bottom pressure retractable seals ensure effortless moved and locked.
Module	700mm - 1200mm maximum.
Panel stacking	Numerous panel stacking options for complete flexibility.
Panel face	MDF,Plywood, woven fabric, Leather,Natural wood veneer, Melamine,Wood moldings, etc.
Finishes	Satin anodised or polyester powder coating to all exposed aluminium components available in a wide range of colours as standard
